Homecare Bed Adjustable Manual Patient Nursing Hospital Bed
1.Three functions controlled by remote control
2.Powder coated cold-rolled punching panel,with ventilation holes
3.Central locking castors controlled by brake pedal.
4.Top class PP&ABS plastic, with corner bumper
5.Collapsible 6 columns Aluminum alloy protective railing
Specifications:
🧩Dimensions: Approx. 2050mm × 960mm × 560mm
🧩Standard Accessories: Mattress, shampoo basin, bedpan, IV pole, dining table, casters, ABS head/foot boards, foldable side rails.
🧩Head & Foot Boards: Made of ABS engineering plastic, hook-on detachable design, footboard is lower than headboard.
🧩Bed Frame: Steel-plastic hybrid construction, load capacity ≥ 240 kg; bed frame made of ≥ 1.2mm high-quality cold-rolled steel.
🧩Construction: Fully automatic welded frame with electrostatic spray coating for durability and corrosion resistance.
🧩Casters: 4 total with full-locking brakes, wear-resistant design.
🧩Side Rails: Stainless steel foldable rails (length: 1150–1200mm), single-hand release mechanism with anti-pinch safety.
🧩IV Pole: 2-section telescopic, shock-resistant design with 2 hooks for multi-bottle infusion.
🧩Mattress: High-density foam mattress matching bed sections; full-zip, removable washable cover, waterproof cover for the toilet cutout area.
🧩Maintenance: Detachable backrest, leg and turning mechanisms for easy service and maintenance.
🧩Key Functions: Backrest lifting, left/right turning, leg bending, dining, infusion, shampooing, foot washing, defecation, silent casters, foldable safety rails.
Adjustable Functions:
Backrest lift: 0–70°±5°
Leg section rise: 0–35°
Leg section drop: 0–45°± 10°
Left turn: 0–45°± 10°
Right turn: 0–45°± 10°
