High Precision Visual Acuity Test Chart Auto Chart Projector Profile Projector
Provide with five kinds of chart of binocular balance, single vertical line, single horizontal line and single chart modes
Description
- By the way of double locating, it would correct errors automatically.
- Offering more clear and sharp pictures.
- Increase the picture density; there are 5 icons in one line.
- The charts are bigger; Size: 33CMx22.5CM (in 5M refraction)
- Projected by wireless remote controller.
- Able to project the charts one by one.
- Standard accessories, the metal board is covered by bias material.
|
Projection distance:
|
2-6(M)
|
|
Projection magnification:
|
30 × (in 5M refraction)
|
|
Projection size:
|
330 × 225mm, Ø275mm (in 5M refraction)
|
|
Numbers of charts:
|
33
|
|
Chart change-over:
|
3 frame/sec
|
|
Numbers of masks:
|
open 1, horizontal line vertical line 8, single isolation 16, r and g 1
|
|
Tilt range:
|
10 ° horizontally as well as vertically
|
|
Projection lamp:
|
6V 20W (halogen lamp)
|
|
Automatic shut-off mechanism:
|
5 minutes
|
|
Electricity:
|
AC 110V/60HZ or 220V/50HZ
|
|
Power consumption:
|
65W
|
|
Dimension:
|
196(W)×292(L)×234(H)(MM)
|
|
Weight:
|
6.5KGS
|
