Surgical Instruments Sterilization Equipment Cassette Low Temperature Plasma Sterilizers
The Low Temperature Plasma Sterilizer is used for rapid sterilization of surgical instruments, heat-resistant, hygroscopic, orthopedic electric drills, electric scalpels, high-quality materials, vinyl materials, and soft and hard endoscopes.
Description
Key usage information
* Hydrogen peroxide concentration: 58% ~ 60%
* Capsule specifications: The capacity of a single capsule is ≥3ml, and a single cassette contains a total of 12 capsules.
* Working temperature: 45℃~60℃
* Sterilization time: rapid sterilization ≤30min; enhanced sterilization ≤50min; lumen sterilization ≤60min
* Energy consumption: ≤1.8 kWh/per pot
Purpose
* The product is used for rapid sterilization of surgical instruments, heat-resistant, hygroscopic, orthopedic electric drills,
electric scalpels, high-quality materials, vinyl materials, and soft and hard endoscopes.
Materials
* Cavity material: Made of high-quality 5052 aluminum, and advanced anti-oxidation treatment technology, which not only enhances the corrosion resistance of the inner cavity in addition to its superior thermal conductivity.
* Box material: Made of ABS material, with high strength, heat resistance and flame retardant properties, making the product safer.
* Door panel material: Made of 5052 aluminum alloy material with anti-oxidation treatment; its thickness is ≥10mm, which greatly improves the ultimate pressure resistance.
* Pipe material: SUS304 stainless steel, sanitary pipe and clamp connection.
* The product is used for rapid sterilization of surgical instruments, heat-resistant, hygroscopic, orthopedic electric drills,
electric scalpels, high-quality materials, vinyl materials, and soft and hard endoscopes.
Materials
* Cavity material: Made of high-quality 5052 aluminum, and advanced anti-oxidation treatment technology, which not only enhances the corrosion resistance of the inner cavity in addition to its superior thermal conductivity.
* Box material: Made of ABS material, with high strength, heat resistance and flame retardant properties, making the product safer.
* Door panel material: Made of 5052 aluminum alloy material with anti-oxidation treatment; its thickness is ≥10mm, which greatly improves the ultimate pressure resistance.
* Pipe material: SUS304 stainless steel, sanitary pipe and clamp connection.
Technical Parameter:
| Overall dimensions | (length × width × height) 750 × 630 × 1495mm |
| Sterilization chamber size | (length × width × height) 610 × 350 × 320mm |
| Total volume | not less than 68L |
| Effective volume | not less than 50L |
| Working temperature | 45℃~60℃ |
| Power | 2.6KVA |
| Weight | 185kg |
