Color Ultrasonic Diagnostic Apparatus

Description

Main specifications and system overview:

3.1 Operating system: Windows 10

3.2 Pulse Wave Doppler

3.3 Directional Energy Doppler

3.4 Real-time triple synchronization

3.5 Spatial Composite Imaging

3.6 Tissue Harmonic Imaging

3.7 2B/4B Imaging

3.8 Support system languages: Chinese, English, French, Russian, Spanish.

3.9 Standard monitor size: 21.5 inch, high-definition medical grade LCD display

3.10 Integrated clipboard: display the saved images at the bottom of the screen, which can be directly transferred or deleted

3.11 With on-site upgradeable functions

3.12 Preset conditions: For different inspections, preset inspection conditions for optimized images, reducing adjustments during operation, and commonly required external adjustments and combined adjustments

3.13 Probe ports: 3 active

3.14 Trapezoidal Imaging

3.15 One-key auto optimization

4. Multiple frequency of different probes：

Convex probe: 2.0MHz, 2.5MHz, 3.0MHz, 3.5MHz, 4.0MHz, 5.5MHz, H4.0MHz, H5.0MHz, multi-frequency (depth: 30-255mm)

Linear probe: 6.0MHz, 7.5MHz, 8.5MHz, 10.0MHz, 12.0MHz, H10.0MHz, multi-frequency (depth: 20-128mm)

Trans-vaginal probe: 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0MHz, multi-frequency (depth: 30-156mm)

Micro convex probe (R15): 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0Mhz, multi-frequency (depth: 30-111mm)

Rectal probe: 4.0MHz, 6.5MHz, 9.0MHz, H8.0Mhz, multi-frequency (depth: 20-110mm)

5.  2D mode

Gain: 0－100, single step 1, visible and adjustable

TGC: 8 segment adjustable

5.3 Dynamic range: 20-280dB, 20 levels visible and adjustable

5.4 Pseudo color: 0-11, visible and adjustable

5.5 Sound power:　5%－100%, single step 5%, visible and adjustable

5.6 Body mark: 6 kinds

5.7 Number of focus: max 6

5.8 Gray Scale: 0-7, visible and adjustable

5.9 Filtering: 0-4

5.10 Scanning range: 50%-100%

5.11 Frame related: 0-4, visible and adjustable

5.12 Real-time display of 14 parameters such as sound power, probe frequency, dynamic range, pseudo color, gray scale, etc., which are adjustable

5.13 Scanning line density: high, medium and low adjustable

5.14 Noise reduction: 0-14

6. Color Imaging Mode:

6.1 Color frame related: 0-12 levels, visible and adjustable

6.2 Color map: 0-7 levels, visible and adjustable

6.3 Color flip: adjustable

6.4 B/C split screen synchronous display function: available

6.5 Color baseline: 11 levels, visible and adjustable

6.6 Color line density: high and low adjustable

6.7 Wall filter: 0-5 level adjustable

7. Pulse Wave Doppler Mode

7.1 Sampling volume angle correction: -80°～80° adjustable

7.2 Sampling volume: 0.5mm-20mm visible and adjustable

7.3 Frequency: 2.5MHz and 3.0MHz visible and adjustable

7.4 Baseline: 9 levels adjustable

7.5 Pseudo-color spectrum: 0-5

7.6 Display layout: 4 kinds, visible and adjustable

7.7  Speed scale: 32.8-328cm/s (varies on different probes)

7.8 Spectrum envelope function: real-time automatic spectrum envelope, manual spectrum envelope and other modes are available, the system automatically analyzes and displays: PSV, EDV, RI, PI, S/D, ACC, HR and other data

7.9  Grayscale: 0-7

7.10  Wall filter: 0-8

7.11  Dynamic range: 10-95dB, single step 5

7.12  Noise reduction: 0-10

7.13  Volume: 0-100

8. Measurement and analysis functions:

8.1 General measurement of distance, area, angle, time, slope, heart rate, speed, acceleration, neck transparent layer, spectrum trace, resistance index/pulsation index, etc.

8.2 With professional measurement packages for different exam organs.

8.3 The color and type of the measuring line can be adjusted(including the activation color and the completion color)

8.4 The display position and font size of the measurement results can be adjusted

8.5 Measurement packages: abdomen, obstetrics, urology, etc.

9. Picture and text management system: Picture saving format: BMP/DCM/JPEG as default

9.1 Built-in 128 GB solid-state hard drive in the main unit to start fast and stable

9.2 Cine loop: 600 frames

9.3 Built-in file information management system: with record number, name, inspection number, inspection date, etc., and can search and manage by number, inspection number, name, etc.

9.4 Report types: 16 kinds

9.5 One-key quick report graphic management

10. Interfaces

2*USB ports, 1*Video, 1*S-Video, 1*DVI, 1*HDMI, 1*RJ-45

 Configurations:

11.1 Color Ultrasonic Diagnostic Apparatus host *1 set

11.2 Probe options:

Convex probe

linear probe

Trans-vaginal probe

Micro-convex probe R15

Rectal probe

11.3 Optional accessories: Thermal printer, puncture guide frame,

11.4 Standard warranty period: 2 years, including machine and probes

11.5 Life-long maintenance after the expiration of the warranty period
