China Classic Portable Handheld Slit Lamp Plastic Optics Instruments for Ophthalmology From Top Suppliers
The YZ3 Portable Digital Slit Lamp Microscope is a lightweight (900g) and advanced veterinary ophthalmology device, featuring high illumination white LED, two-step magnifications (10×, 16×), and a rechargeable battery life of up to 6 hours.
Its angular stereo optical design ensures comfortable observation and clear imaging.
Equipped with multiple filters and adjustable settings, it offers precise diagnostics for animal eye health.
Certified for medical device market access, ensuring compliance with quality standards for professional use in animal hospitals.
Functions as a desktop slit lamp but ideal for pediatrics, Seniors, nursing home, carry-out or vet hospital
Description
Features:
*Magnifications change via dialing the lever
*Functions as a desktop slit lamp but ideal for pediatrics, Seniors, nursing home, carry-out ormobile hospital
*Packed in Alu-Alloy case
*Lighting with LED light source
*Large battery capacity, uniform spot, easy to switch, long servicelife, patients feel more comfortable;
*Lightweight, Single hand operated, total 900g weight, easy to operate and practical enough.
Technical Parameter:
|
Microscope Type
|
Converging Microscope
|
|||
|
Objective Magnification
|
Two Steps Magnifications
|
|||
|
Objective Magnification
|
10×， 16×
|
|||
|
Diopter Adjustment
|
±8D
|
|||
|
Pupil Distance
|
50mm ~ 75mm
|
|||
|
Pupil Distance
|
60mm
|
|||
|
Slit Width
|
0mm ~ 12mm continuously adjustable
|
|||
|
Slit Angle
|
±30°
|
|||
|
Diameter of Light Spot
|
Φ12mm，Φ5mm，Φ1mm，Φ0.2mm
|
|||
|
Filers
|
Color Temperature Compensation, Redfree, Cobalt blue
|
|||
|
Light Source
|
LED
|
|||
|
Maximal Illumination
|
≥30000Lx
|
|||
|
Power Consumption
|
7.4Vd.c Secondary Li-ion Battery
|
|||
|
Working Duration
|
1.5 hours for common use (max illumination)
|
|||
|
Working Duration
|
275mm×243mm×255mm
|
|||
|
Working Duration
|
900g
|
|||
